The Quick Setup menu allows you to quickly confifigure the soft starter for common applications. The soft starter selects the
parameters related to the application and recommends typical settings. You can adjust each parameter according to your actual
needs.
Always set parameter 1A, the rated current of the motor to match the rated current indicated on the motor plate. The recommended
value is the minimum rated current of the starter.
On the screen, the highlighted value is the recommended value, and the value marked with is the loaded value.
——————————————————————————————————————————————————————————————
*Application：Centrifugal pump
-Parameter：Motor rated current ；Starting method ；Adaptive starting curve ；Start ramp time ；Stop mode ；Adaptive；stop curve ；Stop
time
-Suggested Value：Depending on model ；Adaptive Control ；Early acceleration ；10 seconds ；Adaptive Control ；Deceleration ；15 seconds。
*Application：Submersible pump
-Parameter：Motor rated current ；Starting method ；Adaptive starting curve ；Start ramp time ；Stop mode ；Adaptive；stop curve ；Stop
time
-Suggested Value：Depending on the model. ；Adaptive Control ；Speed up early. ；5 seconds ；Adaptive Control ；After decelerating. ；5
seconds。
*Application：Damped fan
-Parameter：Motor rated current ；Starting method ；Current limit
-Suggested Value：Depending on model；Constant current；350%
* Application：Undamped fan
-Parameter：Motor rated current ；Starting method ；Adaptive starting curve ；Start ramp time ；Starting limit time ；Locked rotor time
-Suggested Value：Depending on model ；Adaptive Control ；Constant acceleration ；20 seconds ；30 seconds ；20 seconds
* Application：Screw compressor
-Parameter：Motor rated current ；Starting method ；Start ramp time ；Current limit
-Suggested Value：Depending on model；Constant current；5 seconds；400%
*Application：Reciprocating compressor
-Parameter：Motor rated current ；Starting method；Start ramp time ；Current limit
-Suggested Value：Depending on model ；Constant current ；5 Second ；450%
*Application：Conveyor belt
-Parameter：Motor rated current ；Starting method ；Start ramp time ；Current limit ；Stop mode ；Adaptive stop curve ；Stop time
-Suggested Value：Depending on model ；Constant current ；5 seconds ；400% ；Adaptive Control ；Constant deceleration. ；10 seconds
*Application：Rotary crusher
-Parameter：Motor rated current ；Starting method ；Start ramp time ；Current limit ；Starting limit time ；Locked rotor time
-Suggested Value：Depending on model ；Constant current ；10 seconds ；400% ；30 seconds ；20 seconds
*Application：Jaw Crusher
-Parameter：Motor rated current ；Starting method ；Start ramp time ；Current limit ；Starting limit time ；Locked rotor time
-Suggested Value：Depending on model ；Constant current ；10 seconds ；450% ；40 seconds ；30 seconds
